ABC cable duplex 6AWG (1)Phase and neutral：AAC 7/1.56 XLPE:1.4 mm (2)Print /marking: DN-DS 2019 China Sanhe cable 6 AWG 600V P-A DN-DS 2019 China Sanhe cable 6 AWG 600V P-B (3)Quantity:3300m x 206drums ABC cable triplex 2AWG (1)Phase and neutral： Phase：AAC: 7/2.47 XLPE:1.4 mm, neutral：AAAC :7/2.47 XLPE:1.4 mm, (2)Print /marking: DN-DS 2019 China Sanhe cable 2 AWG 600V P-A DN-DS 2019 China Sanhe cable 2 AWG 600V P-B DN-DS 2019 China Sanhe cable 2 AWG 600V P-N (3)Quantity:1200m x 136 drums
Electric wire THHN THW THWN copper conductor insulation wire Building wire 1. Application The PVC insulated wires belong to the series of laying wires, which are mainly suitable for laying at the fixed places. They are widely used as connectors of driving, lighting, electric equipment, instrument and telecommunication equipment with rated voltage up to 450/750V.Part of the plastic insulated wires are used at the equipment with AC rated voltage up to 300V 2. Standard IEC 60227,IEC 60228,IEC 60332
Brief of Description: Galvanized iron wire, also known as galvanized steel wire , is most used in binding of construction materials or weaving wire mesh products. According to the difference of zinc coating process can be divided into: electro galvanized steel wire and hot-dipped galvanized steel wire. Application: Galvanized steel wire is used for ACSR Core , pulling pole ,overhead conductor,Messenger wire ,Static wire,Guy wire,Guide rail cable Standards: ASTM A-363 Zinc-Coated (Galvanized) Ste
1.Application It Applicable in the AC rated voltage 450 / 750V and below power, house hold appliances, instrumentation and telecommunications equipment lines. 2.Performance Rated voltage: 450 / 750V and below The working temperature: with -90 suffix type wire long-term allowable working temperature should not exceed 90 ℃, other models of long-term allowable operating temperature of the wire should not exceed 70 ℃. When the use of the cable environment to prevent the thermoplastic flow and al
Primarily used for overhead service applications such as street lighting, outer door lighting , and temporary service for construction. To be used at voltages of 600 V phase to phase or less and at conductor temperatures not to exceed 75ºC for Polyethylene insulated conductors or 90ºC for cross linked polyethylene (XLPE) insulated conductors .
The duplex service drop wire primarily used for overhead service drop applications,such as:street lighting.outdoor lighting and temporary service for construction.To be used at voltages of 600v phase-to-phase or less and at at conductor temperatures not to exceed 75℃ for polyethylene(PE) insulated conductors or 90℃ cross-linked polyethylene(XLPE) insulated conductors.
